توضیحات

آی سی TLE8104

Smart Quad Channel Powertrain Switch

درایور انژکتور در ایسیو های :

VALEO ILC – SLC

Description

Quad Low-Side Switch in Smart Power Technology (SPT) with four open drain DMOS output stages. The TLE8104E is protected by embedded protection functions and designed for automotive applications. The output stages can be controlled directly by parallel inputs for PWM applications (e.g. gasoline port injection) or by SPI.The parallel inputs can be programmed to be active high or active low. Diagnosis can be read from an 8-bit SPI or by the external fault pin.

Features

• Overload Protection
• DMOS Overtemperature protection
• Overvoltage protection
• Open load detection
• Low quiescent current mode
• Electrostatic discharge (ESD) protection
• IC Overtemperature warning
• ۸-Bit SPI (for diagnosis and control)
• Short to GND detection
• Green Product (RoHS compliant)
• AEC Qualified

دانلود دیتاشیت آی سی TLE8104

انواع آیسی های خودرویی موجود می باشد.
